YH POWER柴油机水泵因其强大的动力和适应复杂环境的能力，广泛应用于以下场景：
1. 农业灌溉
- 用于农田灌溉、引水、排涝，特别适用于缺乏电力供应的偏远农村和旱灾地区。
- 可配合喷灌、滴灌等现代农业灌溉系统使用。
2. 应急排水与防汛救灾
- 在城市排涝、防洪、抗旱等应急救援中发挥重要作用。
- 用于暴雨、台风等自然灾害后的城市排水、道路抢险。
3. 市政和工业供水
- 用于城市给排水、污水处理厂排水、工业园区供水系统。
- 适用于工业制造企业，如钢铁、化工、电力厂等，需要大流量供水的场景。
4. 建筑工地排水
- 施工现场的地下排水、基坑降水，解决因雨水或地下水渗透造成的积水问题。
- 矿井排水，保障矿工作业安全。
5. 消防系统
- 作为备用消防水源，为城市、高层建筑、大型工厂、油田等提供高压水源。
- 适用于无固定消防水源或电力不稳定的区域。
6. 船舶与港口应用
- 用于船舶压载水排放、海水淡化系统、海上钻井平台供水。
- 码头应急排水和船舶防火灭火。
7.远程输水与山区供水
- 适用于地势复杂、水源点远的山区或高原地区，为居民、牲畜提供稳定的供水。
- 能够克服输水线路长、扬程高的难题。
柴油机水泵因其无需依赖电网、动力强劲、适应性强的特点，广泛应用于各类供水和排水需求场合，是应急救援和工业生产的重要设备。如果你有具体的行业需求，YH POWER可以帮你推荐更适合的产品或技术方案。
1.Maximum flow rate 1000 m³, maximum head 17 m, maximum suction lift 8.5 m;
2. Inlet port size: DN200 (8") x 2mm (in), outlet port size: DN200 (8") x 2mm (in);
3. Engine model SC7H180D2, speed 1500 (r/min), engine rated power 120Kw, cylinder count 6, engine structure is 4-stroke, inline/vertical water-cooled engine, fuel tank can supply the engine to run for >6H;
4. Dimensions: Length L x Width W x Height H: 3100*1750*2350mm, weight 2500kg (subject to actual factory weight);
5. Standard Configuration
Control System: Intelligent LCD Display Controller
Connection method: Flange + disc connection
Pump head: Strong self-priming pump with vacuum assist system
Mobile trailer: Twin-axle, four-wheel, equipped with parking brake, mechanical support feet, mudguards, and vacuum tires
Piping accessories: Inlet pipe: 8 meters/each, 2 pieces in total, equipped with a bottom filter and a Poulson joint, hose: 20 meters/roll, 2 rolls in total.
6.1 Fuel Type: Gasoline;
6.2 Starting method: Electric start; (Provide a color-scan copy of the original test report issued by a third-party institution with the CMA mark, affixed with the bidder's official seal.). )
7. Parameters of the Dumping Intelligent Drainage Unit Drainage Module:
7.1 Pump Control Cabinet Unit: Equipped with overload, phase loss, short circuit, overheating, under-voltage protection, and automatic detection functions;
7.2 Working voltage: Three-phase AC 380V, 50Hz;
7.3 Pump power: >15kW;
7.4. Pump flow rate: >350 m³/h;
7.5, Pump head:>8m;
7.6. Pump weight: <35kg;
The pump comes with a 20-meter-long cable.
8. Remote Monitoring Module for Self-Emptying Smart Drainage Unit:
8.1 The intelligent control system of the submersible pump features control software with recognized copyright, utilizing frequency converters that meet international technical specifications or performance equivalent to top-tier domestic brands for full-process control. (Provide a color scan of the control system's software copyright and affix the bidder's official seal.)
9. Parameters of the lighting module for the dump-type intelligent drainage unit:
9.1 Auxiliary Lighting: Lighting fixtures are installed on both the left and right sides of the cabin;
9.2, Luminous power: 120W;
9.3. Lighting Raising Device: Pneumatic lifting with a raising height > 2.5m;
9.4. Warning Light: Equipped with red flashing warning lights on the top of the four support legs for visual warning purposes;
9.4 Emergency Light: Equipped with an integrated magnetic fixture, featuring illumination and window-breaking capability
